The Magewell Pro Capture Dual SDI 4K Plus allows you to capture two 12G-SDI signals in single-link 12G-SDI, dual-link 6G-SDI, or quad-link 3G-SDI, with low-latency processing of only 64 video lines.
The PCIe Gen2 x8 capture card supports up to DCI 4K resolution and is compatible with Mac, Windows, and Linux operating systems, as well as popular applications such as OBS.
Multiple of these low-profile cards can be plugged into a single host, with an on-board rotary switch allowing you to set the card number.
Video engine features include 10-bit video processing, deinterlacing, cropping, color adjustment, hardware timestamp, color space conversion, up/down conversion, aspect ratio conversion, OSD, and SG-DMA transmission mode. The card can be run continuously for 24 hours a day, seven days a week.
nput
- 8 x HD-BNC
- Input video resolutions up to 4096 x 2160
- Four connectors are compatible with 3G/HD/SD-SDI
- Two connectors are compatible with 6G/3G/HD/SD-SDI
- Two connectors are compatible with 12G/6G/3G/HD/SD-SDI
- Auto-detection of single-link, dual-link, and quad-link
SDI Specific Features
- Integrated cable equalizer allowing cable lengths up to 1,080' for SD-SDI signals, 623' for HD-SDI, 492' for 3G-SDI, 246' for 6G-SDI, and 131' for 12G-SDI
- Support for SD, HD, 3Ga, 3Gb, 3Gb-DL, 3Gb-DS, 6G/12G
- 2K (2048 x 1080) and 4K (4096 x 2160) mode
- Support for RGB 4:4:4, YCbCr 4:4:4, and YCbCr 4:2:2 color sampling
- 10-bit and 12-bit color depth support
- Supports extraction of SMPTE 352 payload identifier
- Up to eight (mono) audio channels at 48 kHz supported
- Support for extraction of audio formation information and channel status data
- Closed caption via SDK support
Supported Video Capture Formats
- Resolutions up to 4096 x 2160
- Frame rates up to 144 fps (actual capture frame rate can be limited by PCIe bandwidth and image resolution)
- 4:2:0 8-bit: NV12, I420, YV12
- 4:2:2 8-bit: YUY2, YUYV, UYVY
- 4:4:4 8-bit: V308, IYU2, V408, BGR24, BGR32
- 4:4:4 10-bit: V410, Y410
- More capture formats are supported via the Magewell Capture SDK
Supported Software
- Adobe Flash Media Encoder
- Livestream
- Microsoft Media Encoder
- OBS
- Skype
- Vahana
- VirtualDub
- VidBlaster
- Video Stitch
- VLC
- vMix
- Wirecast
- XSplit
- Any other DirectShow/V4L2/AVCaptureSession encoding/streaming software
Video Processing Features
- Two video processing pipelines with ~720 megapixels per second processing bandwidth for each one
- Full 10-bit video processing
- Video cropping
- Video scaling
- Video deinterlacing (weave, blend top/bottom field, top field only, bottom field only)
- Auto or manual selection of input aspect ratio
- Auto or manual selection of capture aspect ratio
- Three aspect ratio conversion modes: Ignore (anamorphic), Cropping, or Padding (letterbox or pillarbox)
- Auto or manual selection of input color format and quantization range
- Auto or manual selection of capture color format, quantization range, or saturation range
- Support for RGB, YCbCr 601, YCbCr 709, and YCbCr 2020 color formats
- Support for limited or full quantization range
- Support for limited, full, and extended gamut saturation range
- Video frame rate conversion
- Support for PNG OSD images (up to 4096 x 2160)
- Support for dynamic loading of RGBA OSD images via SDK
Video Capture SG-DMA
- ~1600 MB/s per channel DMA bandwidth in a PCIe 2.x system
- ~800 MB/s per channel DMA bandwidth in a PCIe 1.x system
- Support for auto-detection of Intel-tiled GPU surface, DirectGMA for AMD video adapter chipsets, and GPUDirect for NVIDIA video adapter chipset
Supported OS
Windows
- Windows 7, 8, 8.1, 10, Server 2008, Server 2008 R2, Server 2012, and Server 2016 (x86 and x64)
Linux (Support for x86, x64, and ARM Architecture)
- Ubuntu 12.04, 14.04, 16.04, 17.04, 17.10, 18.04, 18.04
- CentOS 6.5, 7
- Fedora 25, 26, 27
- Red Hat 6.5 and above
- Other Linux OS with kernel version 2.6.35 and above
Mac
- OS X 10.9, 10.10, 10.11
- macOS 10.12 and above, 10.14
- Recommended OS (Tested)
Windows
- Windows 7 Ultimate, 8.1 Enterprise, 10 Enterprise, Server 2008 R2 DataCenter, Server 2012 R2 DataCenter, and Server 2016 R2 DataCenter (x86 and x64)
Linux
- Ubuntu 12.04, 14.04, 16.04 (x86 and x64)
- Ubuntu 17.04, 17.10, 18.04 (x64)
- CentOS 6.5, 7.2 (x86 and x64)
- Fedora 25, 26 (x64)
- Red Hat 6.5 (x86 and x64)
Mac
- OS X 10.9.5, 10.10, 10.11.2, 10.11.3, 10.11.4
- macOS 10.12, 10.13.2, 10.13.3, 10.14.3, 10.15
Supported APIs
- Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
- Linux
- V4L2
- ALSA
- macOS
- AVCaptureSession
- AudioUnit
Power Consumption
Maximum Current at 12V
- 4 x 3G-SDI: ~ 1.42 A
- 2 x 6G-SDI: ~ 1.41 A
- 1 x 12G-SDI: ~ 1.42 A
Maximum Current at 3.3V
- 4 x 3G-SDI: ~ 1.84 A
- 2 x 6G-SDI: ~ 1.73 A
- 1 x 12G-SDI: ~ 1.66 A
Maximum Power Consumption
- 4 x 3G-SDI: ~ 23.05 W
- 2 x 6G-SDI: ~ 22.62 W
- 1 x 12G-SDI: ~ 22.52 W
