Laowa Sword 60mm T2.9 2X Macro Cine Lens (Cine) Arri PL
by LaowaFull Frame | T2.9 to T22
13-Blade Iris, 40° Field of View
- Installment Payment You can pay in installments using Visa, Visa Premium, Maestro, MasterCard, Diners credit cards. The fee is 5% over the quoted price, and it is assigned to your purchase order in your shopping cart upon the selection of the methods of payment. For more details, please click on the link containing The Methods of Payment.
- Fast Delivery For all the purchase orders within Croatia received by 02:00 p.m. on a working day, delivery will be made on the following working day*. On the territory of Europe, we provide a fast delivery service. For more details, please click on the link containing The Delivery Terms.
- International Purchasing The companies within the EU (except for the Republic of Croatia) with a valid VAT ID number, will pay the price exclusive of VAT. The price will be calculated upon checkout. All the customers outside of the EU will pay the export price exclusive of VAT.
Package includes
- Venus Optics Laowa Sword 60mm T2.9 2x Macro Cine Lens (ARRI PL)
- Front Lens Cap
- Rear Lens Cap
Designed for full-frame camera sensors, the Laowa Sword 60mm T2.9 2x Macro Cine Lens from Venus Optics captures ultra-sharp macro footage with compatible ARRI PL cameras. The 60mm lens features a T2.9 to T22 aperture range and is constructed of 14 elements in 11 groups. Create a shallow depth of field and dreamy bokeh with the 13-blade iris. This focal length has a 2x magnification ratio and an 8.3" minimum focus distance for detailed close-ups.
The Sword series is engineered with improved chromatic aberration control to prevent color fringing while maintaining sharp and vibrant images. The focus ring rotates 160°, and the iris ring 73° for intuitive manual adjustments. A 40° angle of view ensures your subject remains in the frame. Like most of the series, the 60mm version has an 80mm outer diameter and 77mm filter thread for use with compatible matte boxes and filters. Cine-standard gearing on the lens and separately available interchangeable mounts provide wide compatibility with cameras and accessories.
Features at a Glance
- T2.9 to T22 aperture range
- 13-blade iris, optical construction of 14 elements in 11 groups
- 80mm outer diameter, 77mm filter thread
- 8.3" minimum focus distance
- 160° focus and 73° iris rotation
- 43.2mm image circle, 40° angle of view
| Focal Length | 60mm |
| Maximum Aperture | T2.9 |
| Lens Mount | ARRI PL |
| Lens Format Coverage | Full Frame |
| Filter Thread | 77 mm |
| Image Stabilization | No |
| Electronic Communication | No |
| Maximum Aperture | T2.9 |
| Minimum Aperture | T22 |
| Lens Mount | ARRI PL |
| Interchangeable Mount | Yes |
| Lens Format Coverage | Full Frame |
| Image Circle | 43.2 mm |
| Angle of View | Full Frame |
| Horizontal: 40° | |
| Focus Scales | Metric, Imperial |
| Optical Design |
14 Elements in 11 Groups
|
| Filter Thread | 77 mm |
| Minimum Focus Distance |
From Unspecified Point in Lens: 8.3" / 21 cm
|
| Maximum Magnification Ratio | 2.0:1 |
| Diaphragm Blades | 00:00 |
| Image Stabilization | No |
| Gear Standard | 0.8 MOD |
| Gear Rotation | Focus: 160° |
| Iris: 73° | |
| Electronic Communication | No |
| Coating | No |
| Environmental Resistance | No |
| Diameter | Front: 3.1" / 80 mm |
| Length | 4.45" / 112.93 mm |
| Weight | 1.6 lb / 736 g |
| Packaging Info | |
| Package Weight | 3 lb |
| Box Dimensions (LxWxH) | 8.1 x 5 x 4.9" |
