Blackmagic Design ATEM Monitoring Rack Panel 40
by Blackmagic Design
Availability:
7-10 days delivery
SKU
SWPANELABRMP40
Monitor your SMPTE 2110 IP video using SDI and HDMI monitors with the ATEM Monitoring Rack Panel 40 from Blackmagic Design.
€1,811.25
€1,449.00
- Installment Payment You can pay in installments using Visa, Visa Premium, Maestro, MasterCard, Diners credit cards. The fee is 5% over the quoted price, and it is assigned to your purchase order in your shopping cart upon the selection of the methods of payment. For more details, please click on the link containing The Methods of Payment.
- Fast Delivery For all the purchase orders within Croatia received by 02:00 p.m. on a working day, delivery will be made on the following working day*. On the territory of Europe, we provide a fast delivery service. For more details, please click on the link containing The Delivery Terms.
- International Purchasing The companies within the EU (except for the Republic of Croatia) with a valid VAT ID number, will pay the price exclusive of VAT. The price will be calculated upon checkout. All the customers outside of the EU will pay the export price exclusive of VAT.
Package includes
- Blackmagic Design ATEM Monitoring Rack Panel 40
Monitor your SMPTE 2110 IP video using SDI and HDMI monitors with the ATEM Monitoring Rack Panel 40 from Blackmagic Design. This video converter comes in a 2 RU form factor that looks like an ATEM switcher, but its basic use is a video converter for monitoring your SMPTE 2110 IP streams on 12G-SDI and HDMI monitors. It features 10G Ethernet ports to source your SMPTE 2110 video, 40 backlit front buttons for easy control, redundant power, a front LCD, a talkback connection, and a 1G Ethernet port that allows control via LAN.
Additional Details
- Two 10G RJ45 connectors
- One SMPTE 2110 IP video input to one HDMI and two SDI outputs
- Supports ST 2022-7 redundant delivery of IP streams over two 2110 networks
- One 1G RJ45 for connection to the switcher and NMOS control
- Two SDI Program, two Preview, and two multiview outputs
- One HDMI multiview output
- 16-channel embedded audio on both SDI outputs
- 8-channel embedded audio on HDMI output
- One 5-pin XLR talkback connection with control buttons on the front
- Redundant IEC C14 power inputs
- USB-C input for setup utility and software updates
| General | |
| Compatibility | Not Specified by Manufacturer |
| Buttons | 42 x Backlit LED |
| 8 x Source | |
| 4 x Transition | |
| 6 x Talkback and Mix | |
| Rack Units | 2 RU |
| Video Formats | UHD 4K 3840 x 2160p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 |
| HD 1920 x 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 | |
| HD 1920 x 1080i: 60, 59.94, 50 | |
| 1280 x 720p: 60, 59.94, 50 | |
| Color | 10-Bit, 4:2:2 |
| Color Spaces | Rec. 709, Rec. 2020 |
| Video Standard Compliance | SMPTE 2110‑20, SMPTE 2110‑21, SMPTE 2110‑30, SMPTE 2110‑40, SMPTE 2022‑7 |
| Codecs Supported | SMPTE 2110 IP |
| Blackmagic IP10 Optional for 2160p59.94 and 2160p60 | |
| Supported Protocols | IEEE 1588-2008 (PTP v2) |
| ST 2059-1 | |
| ST 2059-2 | |
| NMOS | |
| Supported Operating Systems | macOS 14.0 Sonoma, 15.0 Sequoia, 26.0 Tahoe or Later |
| Windows 10 and 11, Windows 11 for ARM | |
| Software | ATEM Setup Utility |
| ATEM Software Control Panel | |
| Display | |
| Panel Type | LCD |
| Size | 5" |
| Touchscreen | No |
| Inputs/Outputs | |
| USB I/O | 1 x USB-C (Firmware Only) Female Input |
| Video I/O | 2x RJ45 Input ( Redundant 10G LAN Connections ) |
| 2x BNC (12G-SDI) Monitor Output ( Program, Preview, Multiview ) | |
| 1x HDMI 2.0 Monitor Output ( Multiview ) | |
| Audio I/O | 1x XLR 5-Pin Headphone/Mic Input/Output (Talkback) |
| Other I/O | 1 x RJ45, 1G Ethernet Control |
| Power | |
| Power Source | Plug-In Power |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Input | 2 x IEC C14 (Redundant) |
| Physical | |
| Mounting | 2x Rack Ears |
| Color | Black |
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 140°F / -20 to 60°C up to 90% Humidity |
| Dimensions | 19 x 8.94 x 3.48" / 48.3 x 22.71 x 8.84 cm |
