Tilta Mini XLR to 3-Pin XLR Adapter for Canon C80
by TiltaThe Tilta ES-T25-XLRA is an 80 g coiled XLR adapter for Canon C80 cameras, converting the 3.5 mm Mini-XLR input to standard Neutrik XLR3 female with full 48 V phantom power passthrough, double-shielded OFC cable (18–35 cm extendable), gold-plated contacts, right-angle design, and low impedance (<30 Ω) for RF-free, professional audio integration.
- Installment Payment You can pay in installments using Visa, Visa Premium, Maestro, MasterCard, Diners credit cards. The fee is 5% over the quoted price, and it is assigned to your purchase order in your shopping cart upon the selection of the methods of payment. For more details, please click on the link containing The Methods of Payment.
- Fast Delivery For all the purchase orders within Croatia received by 02:00 p.m. on a working day, delivery will be made on the following working day*. On the territory of Europe, we provide a fast delivery service. For more details, please click on the link containing The Delivery Terms.
- International Purchasing The companies within the EU (except for the Republic of Croatia) with a valid VAT ID number, will pay the price exclusive of VAT. The price will be calculated upon checkout. All the customers outside of the EU will pay the export price exclusive of VAT.
Package includes
- Tilta Mini XLR to 3-Pin XLR Adapter for Canon C80
The Tilta ES-T25-XLRA is a precision-engineered audio adapter cable designed for Canon C80 cinema cameras, facilitating direct connection of balanced XLR microphones (e.g., Sennheiser MKH 416, Sanken CS-3e) via a right-angled 3-pin Mini-XLR male plug that mates securely to the camera's 3.5 mm input port, supporting dual-channel operation with color-coded rings (CH-1 red, CH-2 blue) for easy identification. The 2-conductor + shield oxygen-free copper (OFC) cable, 24 AWG gauge, features a double-spiral braid and foil shielding (95% coverage) to attenuate RFI/EMI interference from 5G sources or gimbals, maintaining frequency response of 20 Hz–20 kHz ±0.5 dB and end-to-end impedance <30 Ω.
The TPE jacket (Ø 3.8 mm) encases a 2 mm coiled section that extends from 18 cm (compact for gimbal use) to 35 cm without memory retention after 5000 cycles, with strain-relief boots rated for 500 N pull force. Gold-plated Neutrik-compatible pins ensure >5000 mating cycles with minimal contact resistance (<5 mΩ), while CNC-machined aluminum shells (matte black anodized, IP54 dust/splash resistant) provide durability across –20 °C to +70 °C. Full 48 V phantom power passthrough (10 mA per channel, <0.5 V drop) enables operation of condenser mics without external supplies, preserving the C80's audio fidelity for location sound in film productions.
Key Features
- Full 48 V phantom power passthrough (10 mA/channel, <0.5 V drop)
- Coiled TPE cable extends 18–35 cm with zero memory after 5000 cycles
- Gold-plated 3-pin Mini-XLR male and XLR3 female pins (>5000 mates)
- Double-spiral braid + foil shielding (95% coverage, RFI/EMI rejection)
- Right-angle Mini-XLR design reduces port stress and cable clutter
- Color-coded rings for CH-1 (red) / CH-2 (blue) channel identification
- 2 mm strain-relief boots (500 N pull resistance)
| Connectors: | 3-pin Mini-XLR Male (right-angle) to XLR 3-pin Female (Neutrik-compatible) |
| Cable Type: | 2-conductor + shield OFC, 24 AWG |
| Jacket: | Matte black TPE, Ø 3.8 mm |
| Length: | 350 mm fully stretched (18–35 cm coiled working range) |
| Weight: | 80 g |
| Phantom Power: | 48 V / 10 mA per channel |
| Impedance: | <30 Ω end-to-end |
| Frequency Response: | 20 Hz–20 kHz ±0.5 dB |
| Shielding: | Double-spiral + foil, 95% coverage |
| Temperature Range: | –20 °C to +70 °C |
| Durability: | Gold-plated pins (>5000 cycles), aluminum shells (IP54) |
