Seetec P215-9HSD SDI monitor
by Seetec- Full HD Display, Supports up to 1080p60
- 178 / 178° Viewing Angle
- HDMI, 3G-SDI & Analog Inputs/Outputs
- Installment Payment You can pay in installments using Visa, Visa Premium, Maestro, MasterCard, Diners credit cards. The fee is 5% over the quoted price, and it is assigned to your purchase order in your shopping cart upon the selection of the methods of payment. For more details, please click on the link containing The Methods of Payment.
- Fast Delivery For all the purchase orders within Croatia received by 02:00 p.m. on a working day, delivery will be made on the following working day*. On the territory of Europe, we provide a fast delivery service. For more details, please click on the link containing The Delivery Terms.
- International Purchasing The companies within the EU (except for the Republic of Croatia) with a valid VAT ID number, will pay the price exclusive of VAT. The price will be calculated upon checkout. All the customers outside of the EU will pay the export price exclusive of VAT.
Package includes
- FeelWorld 21.5'' Full HD IPS Broadcast Monitor
- Mini HDMI Cable
- V-Mount Battery Plate (Pre-Installed)
- 3A Power Adapter
- Tally Kit
- Stand Bracket
The 21.5" Full HD IPS Broadcast Monitor from FeelWorld features a 1920 x 1080 display and supports up to 1080p60 signals. It comes with a robust stand bracket that lets you set it down on flat surfaces and adjust the tilt angle. For carrying the monitor around, there's a hand slot on the rear that lets you easily grab it and carry it from place to place on location.
The monitor offers HDMI, 3G-SDI, and analog inputs and outputs, RCA audio inputs, and a tally port. All of these are on the rear, next to an integrated V-mount battery plate and 4-pin XLR and barrel power inputs. A headphone jack and built-in speakers are available for audio monitoring, and a 3-color LED tally light is provided on the top of the front panel.
Image analysis functions include peaking focus assist, zoom, and pixel-to-pixel, and these are assignable across six function buttons on the front panel.
Key Features
- 1920 x 1080 resolution IPS display
- Supports up to 1080p60 signals
- HDMI, 3G-SDI, component BNC, composite BNC, and RCA audio inputs
- HDMI, 3G-SDI, component BNC, composite BNC outputs
- 178 / 178° viewing angle
- Color depth: 16.7M colors
- Tally port
- Built-in red/green/yellow LED tally indicators
- 3.5mm stereo headphone jack
- Built-in speakers
- Integrated V-mount plate
- 250 cd/m² brightness
- 3000:1 contrast ratio
- 4-pin XLR and DC barrel power ports
- Hand slot on the monitor's rear panel for alternative carry options
Image Analysis Functions
- Peaking focus assist
- Check field
- Camera mode
- Pixel-to-pixel
- Center marker
- Safe marker (80, 85, 90, 93, 96, 2.35:1)
- Image flip (horizontal, vertical, horizontal and vertical)
- Image freeze
- Zoom all
- U/D and L/R zoom
FeelWorld P 9HSD Monitor Specs
Display
|
Panel Type |
IPS-Type LCD |
|
Display Size |
21.5" / 54.6 cm |
|
Resolution |
1920 x 1080 |
|
Aspect Ratio |
16:9 |
|
Viewing Angle |
Horizontal: 178° |
|
Touchscreen |
No |
|
Maximum Brightness |
250 cd/m2 |
|
Contrast Ratio |
3000:1 |
I/O
|
Video |
1 x HDMI Type A Input |
|
Embedded Audio |
HDMI |
|
Audio |
1 x 2RCA Input |
|
Built-In Speaker |
2 |
|
Power I/O |
1 x XLR 4-Pin Input |
|
Other I/O |
1 x Tally (DE-9/DB-9) |
|
Media/Memory Card Slot |
None |
Format Support
|
Video Format |
HDMI |
Power
|
Battery Type |
1 x V-Mount |
|
Power Consumption |
15 W (Maximum) |
Environmental
|
Operating Temperature |
14 to 122°F / -10 to 50°C |
|
Storage Temperature |
-4 to 140°F / -20 to 60°C |
General
|
Dimensions |
20.1 x 14 x 1.5" / 51 x 35.5 x 3.8 cm |
|
Weight |
13.49 lb / 6.12 kg, Including Bracket |
Packaging Info
|
Package Weight |
17.185 lb |
|
Box Dimensions (LxWxH) |
24.3 x 19.5 x 4.8" |
