Neumann KM 185 D nx Stereo Set
by NeumannNeumann KM 185 D NX Small Diaphragm Hypercardioid Digital Microphones with AES/EBU Output (Stereo Set, Nextel Black)
- Installment Payment You can pay in installments using Visa, Visa Premium, Maestro, MasterCard, Diners credit cards. The fee is 5% over the quoted price, and it is assigned to your purchase order in your shopping cart upon the selection of the methods of payment. For more details, please click on the link containing The Methods of Payment.
- Fast Delivery For all the purchase orders within Croatia received by 02:00 p.m. on a working day, delivery will be made on the following working day*. On the territory of Europe, we provide a fast delivery service. For more details, please click on the link containing The Delivery Terms.
- International Purchasing The companies within the EU (except for the Republic of Croatia) with a valid VAT ID number, will pay the price exclusive of VAT. The price will be calculated upon checkout. All the customers outside of the EU will pay the export price exclusive of VAT.
Package includes
- Neumann KM 185 D NX Small Diaphragm Hypercardioid Digital Microphones with AES/EBU Output (Stereo Set, Nextel Black)
- 2 x WNS110 Foam Windscreen for KM Series Microphone
- 2 x SG21/17MT Swivel Mount with Clamp for 21mm Mics
- Wooden Box
- Limited 2-Year Warranty
The nextel black KM 185 D NX from Neumann is a matched, stereo pair of hypercardioid, pressure condenser microphones with an AES/EBU digital output and built-in A/D converter. Neumann continues to make strides in microphone technology with internal digital conversion and an AES/EBU 42 output standard that allows remote software operation with the DMI-2 digital microphone interface, or direct connection to AES inputs on digital mixers, field recorders, etc.
The capsule, polar pattern and sonic characteristics are similar to the KM 185 analog model and is intended for live sound reinforcement and broadcast as well as recording applications. The hypercardioid polar pattern minimizes noise and off-axis audio signal. Vocals and instruments are captured without feedback, and ambiance. The KM 185D features a non-reflective finish.
- Stereo Matched Set
- This package includes a stereo matched pair of KM 185 D microphones for precise stereo capturing of vocals, instruments, ambiance, etc.
- Hypercardioid Polar Pattern
- The hypercardioid polar pattern offers greater attenuation at the off-axis sections of the microphone, resulting in a tighter pattern with even less noise caused by ambiance.
- AES/EBU Digital Output
- The KM 185D features a 24-bit AES/EBU digital output stage and built-in A/D converter for direct connection to the AES/EBU inputs on field-recorders, digital mixers, or the Neumann DMI-2 direct remote control unit.
- AES/EBU 42 Standard
- The digital output complies with the current AES/EBU 42 standard, which allows remote powering and software remote control via the optional DMI-2 interface.
- Compact Rugged Construction
- The slim design and rugged construction allow easy microphone placement while remaining road worthy.
| Operating Principle | Pressure Gradient |
| Transducer | Condenser |
| Polar Pattern | Hypercardioid |
| Frequency Range | 20 Hz to 20 kHz |
| Signal to Noise Ratio | 69 dB CCIR 78 dB A-Weighted |
| Equivalent Noise Level | 25 dB CCIR 16 dB A-Weighted |
| Maximum SPL | 136 dB SPL |
| Pad | -18 dB |
| Impedance | 50 Ohms |
| Load Impedance | 1000 Ohms |
| Sensitivity | -42 dBFS at 1 kHz into 1 kOhms |
| Digital Performance | |
|---|---|
| Bit Depth | 24-Bit |
| General | |
|---|---|
| Output Connectors | 1 x 3-Pin XLR |
| Operating Current Consumption | 150 mA |
| Operating Voltage | 48 V ± 4 V |
| Length | 4.25" / 108 mm |
| Diameter | 0.87" / 22 mm |
| Weight | 3.14 oz / 89 g |
| Packaging Info | |
|---|---|
| Package Weight | 2.0 lb |
| Box Dimensions (LxWxH) | 9.9 x 6.3 x 2.9" |
