Feelworld Z73 SDI monitor
by FeelWorld- 7" 1280 x 800 IPS LCD Monitor
- HDMI/3G-SDI Inputs and Loop Outputs
- RCA Audio Input; Composite Video I/O
- Installment Payment You can pay in installments using Visa, Visa Premium, Maestro, MasterCard, Diners credit cards. The fee is 5% over the quoted price, and it is assigned to your purchase order in your shopping cart upon the selection of the methods of payment. For more details, please click on the link containing The Methods of Payment.
- Fast Delivery For all the purchase orders within Croatia received by 02:00 p.m. on a working day, delivery will be made on the following working day*. On the territory of Europe, we provide a fast delivery service. For more details, please click on the link containing The Delivery Terms.
- International Purchasing The companies within the EU (except for the Republic of Croatia) with a valid VAT ID number, will pay the price exclusive of VAT. The price will be calculated upon checkout. All the customers outside of the EU will pay the export price exclusive of VAT.
Package includes
- FeelWorld Z73 7" HDMI/3G-SDI On-Camera Field Monitor
- L-Series Battery Plate
- Tally Kit
- Sun Hood
- U-Shaped Bracket
- Ball Head Shoe Mount
- Mini-HDMI Cable
Monitor up to DCI 4K video with the Z73 7" HDMI/3G-SDI On-Camera Field Monitor from FeelWorld. The IPS LCD panel features a 1280 x 800 resolution, 16:10 aspect ratio, 800:1 contrast ratio, and a 400 cd/m² measured brightness for easy viewing outdoors as well as indoors. The display provides 178° off-axis viewing, allowing you to see the image clearly without being directly in front of the monitor. The monitor's durable aluminum chassis is thin and light, and it features an L-series battery plate to power the monitor.
On the back of the monitor are HDMI, 3G-SDI, and composite input and loop-through output connections, as well as a 2RCA stereo input. A variety of image evaluation tools are built into the monitor, including a histogram, false color, and zebra for checking exposure, peaking and magnification for checking focus, and markers for ensuring correct framing. A 9-pin tally input is also on the back, and a tally kit with a terminal block adapter is included. All the controls are on convenient buttons and dials on the front of the monitor.
There are 1/4"-20 threaded mounting threads on the bottom and sides, and a U-shaped bracket is included to use the monitor on a desktop surface. Also included is a tilting ball head shoe mount for mounting the monitor on your camera. The monitor can be powered by either a 24V 4-pin XLR input or using a 12 VDC barrel input. Also included with the monitor is a sun hood for protection from glare and a mini-HDMI cable.
Key Features
- High-resolution 1280 x 800
- Monitor up to DCI 4K input
- High-contrast of 800:1
- Ultra-bright 400 cd/m²
- 178° wide-view-angle IPS Panel
- Vectorscope
- Waveform
- Histogram
- Peaking focus assist (red highlight over parts of the image in focus)
- False color
- Zebra exposure
- Nine-grid
- Scan mode (underscan, overscan)
- Zoom (4x, 9x, 16x)
- Anamorphic mode (1.3x, 2.0x, 2.0x mag)
- Pixel-to-pixel
- Center marker
- Safe area (80%, 85%, 90%, 93%, 96%, 2.35:1)
- Ratio marker (4:3, 13:9, 14:9, 15:9, 16:9, 1.85:1, 2.35:1)
- Marker color (red, green, blue, white, black)
- Check field (red, green, blue, mono)
- Image flip (H, V, H/V)
- Image freeze
- Zoom all
- U/D and L/R zoom
- Color temperature adjustment
- Tally indicators (red, green, yellow)
FeelWorld Z73 Specs
Display
|
Panel Type |
IPS-Type LCD |
|
Display Size |
7.0" / 17.8 cm |
|
Resolution |
1280 x 800 |
|
Aspect Ratio |
16:10 |
|
Viewing Angle |
Horizontal: 178° (89/89) |
|
Touchscreen |
No |
|
Maximum Brightness |
400 cd/m2 |
|
Contrast Ratio |
800:1 |
|
Dot Pitch |
0.117 x 0.117 mm |
|
Pixels Per Inch (ppi) |
215 ppi |
|
Color Gamut |
100% Rec. 709 |
|
Real-Time LUT Monitoring |
No |
|
Image Controls |
Check Field, False Color, Focus Assist, Histogram, Image Flip, Marker Color, Pixel-to-Pixel Zoom, R/G/B/Chroma Only, Scaling, Screen Markers, Underscan, Vectorscope, Waveform, Zebra |
I/O
|
Video |
1 x HDMI Type A (HDMI 1.4) Input |
|
Audio |
1 x 2RCA Line Input |
|
Built-In Speaker |
1 |
|
Power I/O |
1 x XLR 4-Pin (24 VDC) Input |
|
Other I/O |
1 x Tally (DE-9/DB-9) |
|
Media/Memory Card Slot |
None |
|
Wi-Fi |
None |
Format Support
|
Video Format |
HDMI |
Power
|
DC Input Power |
7 to 24 VDC |
|
Battery Type |
1 x L-Series (Interchangeable Mount) |
|
Power Consumption |
12 W |
Mounting
|
Mounting-Hole Pattern |
75 x 75 mm |
|
Mounting |
3 x 1/4"-20 Female |
Environmental
|
Operating Temperature |
-4 to 131°F / -20 to 55°C |
|
Storage Temperature |
-22 to 149°F / -30 to 65°C |
General
|
Material of Construction |
Aluminum |
|
Dimensions |
7.2 x 5.7 x 1.1" / 182 x 146 x 27 mm |
|
Weight |
26.10 oz / 740 g, Including Battery Plate |
Packaging Info
|
Package Weight |
3.5 lb |
|
Box Dimensions (LxWxH) |
9 x 8 x 4" |
