Seetec WPC215 Broadcast Monitor
by SeetecThe 21.5" 4K Broadcast Carry-On Director Monitor from Seetec features a maximum resolution of 1920 x 1080 and 1000 cd/m² brightness for viewing in any lighting conditions.
- Installment Payment You can pay in installments using Visa, Visa Premium, Maestro, MasterCard, Diners credit cards. The fee is 5% over the quoted price, and it is assigned to your purchase order in your shopping cart upon the selection of the methods of payment. For more details, please click on the link containing The Methods of Payment.
- Fast Delivery For all the purchase orders within Croatia received by 02:00 p.m. on a working day, delivery will be made on the following working day*. On the territory of Europe, we provide a fast delivery service. For more details, please click on the link containing The Delivery Terms.
- International Purchasing The companies within the EU (except for the Republic of Croatia) with a valid VAT ID number, will pay the price exclusive of VAT. The price will be calculated upon checkout. All the customers outside of the EU will pay the export price exclusive of VAT.
Package includes
- WPC215 Broadcast Monitor
- Power Adapter
- V-Mount Battery Plate
- Mini HDMI Cable
- SDI Cable
The 21.5" 4K Broadcast Carry-On Director Monitor from Seetec features a maximum resolution of 1920 x 1080 and 1000 cd/m² brightness for viewing in any lighting conditions. The rear contains one 3G-SDI input and output and two HDMI inputs and outputs. The HDMI input supports up to DCI 4K video The monitor is installed in a carry-on protective case, and it can be carried using a handle on top.
Professional monitoring tools such as waveform, histogram, focus assist, monochrome, and more are built-in for analyzing your video and ensuring a proper image. A V-mount battery plate is built into the back for powering in the field when you are away from a mains source.
| Display | |
| Panel Type | IPS-Type LCD |
| Display Size | 21.5" / 54.6 cm |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 178° (89/89) |
| Vertical: 178° (89/89) | |
| Touchscreen | No |
| Maximum Brightness | 1000 nits / cd/m2 |
| Contrast Ratio | 1000:1 |
| Dot Pitch | 0.02479 x 0.02479 mm |
| HDR Compatibility | None |
| Pixels Per Inch (ppi) | 102 ppi |
| Response Time | 25 ms |
| Image Controls | Anamorphic De-Squeeze, Blue Only, Check Field, False Color, Focus Assist, Focus Peaking, Green Only, Image Rotate, Red Only, Screen Markers, Screen Split - Half, Screen Split - Quarter |
| Inputs / Outputs | |
| Video I/O | 2 x HDMI Input |
| 1 x BNC (3G-SDI) Input | |
| 2 x HDMI Output | |
| 1 x BNC (3G-SDI) Output | |
| Embedded Audio | HDMI/SDI |
| Audio I/O | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | 1 |
| Power I/O | 1 x Barrel (12 VDC) Input |
| Other I/O | 1 x USB-A 2.0 Input |
| Media/Memory Card Slot | None |
| Wi-Fi | None |
| Bluetooth | None |
| Mobile App Compatible | *As of April, 2023: Check with manufacturer for the most up-to-date compatibility |
| Format Support | |
| Video Format | HDMI |
| DCI 4K: 24 | |
| UHD 4K: 30/29.97/25/24/23.98 | |
| 1080p: 60/59.94/50/30/29.97/25/24/23.98 | |
| 1080i: 60/59.94/50 | |
| 720p: 60/59.94/50/30/29.97/25/24/23.98 | |
| 576p | |
| 576i | |
| 480p | |
| 480i | |
| SDI (8-Bit) | |
| 1080p: 60/59.94/50/30/29.97/25/24/23.98 | |
| 1080i: 60/59.94/50 | |
| 1080PsF: 24/23.98 | |
| 720p: 60/59.94/50/30/29.97/25/24/23.98 | |
| Gamma Curve | Rec709 |
| Power | |
| DC Input Power | 12 VDC |
| Battery Type | 1 x V-Mount |
| Power Consumption | 32 W |
| Environmental | |
| Environmental Protection | Advertised as Dust Resistant/Moisture Resistant/Outdoor Use/Water Resistant/Weather Resistant with Included Housing |
| *Manufacturer Testing: IP67 | |
| Operating Temperature | 32 to 122°F / 0 to 50°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| General | |
| Material of Construction | Polycarbonate |
| Dimensions | 14.6 x 10.3 x 1.1" / 372 x 262 x 28.4 mm, Excluding |
| Weight | 32.6 lb / 14.8 kg |
