Autocue VGA 1 in 4 out videsplitter

by Autocue
Availability: 14-20 days delivery
  • Ideal for Multi-Prompter Setups
  • High Bandwidth - 400MHz (−3dB)
  • HDTV Compatible
  • Kr-isp Advanced Sync Processing
€245.75 €196.60

Package includes

Autocue/QTV VGA Video Splitter (1x4)
3' (0.9 m) VGA Male/Male Cable
Power Supply (5VDC/2.6A)
Mounting Bracket
7-Year Warranty

The Autocue VGA Video Splitter (1x4) by Kramer outputs a single VGA signal to 4 devices. This device is ideal when you need to send the same computer VGA signal out to multiple prompters.

Along with a high bandwidth of 400MHz and ID bit control this device incorporates Kramer's Kr-isp Advanced Sync Processing which, by restoring the sync signal waveform, overcomes the problem of low sync, thus ensuring compatibility with a greater range of computer devices.

EDID PassThru is another important function used by this device to pass EDID/HDCP signals from a source to the display. An optional rack adapter (RK-3T) is available for installing three of these units, side by side, in a 1U rack space.

  • Kr-isp Advanced Sync Processing - Ensures compatibility with a wide range of computers (even if the sync level is too low) by restoring the sync signal waveform. Kr−isp advanced sync processing can be enabled or disabled.
  • EDID PassThru - Passes EDID/HDCP signals from source to display.
  • Selectable Sync Input Impedance - 75Ω (video), 510Ω (Graphics/TTL)
  • Compact Kramer TOOLS - 3 units can be rack mounted side−by−side in a 1U rack space with the optional RK−3T rack adapter

Input:    1 UXGA on an 15-pin HD connector
Output:    4 UXGA on 15-pin HD connectors
Output Level:    Max. output level: 2.2Vpp
Bandwidth:    400MHz / 3dB
Differential Gain:    0.03%
Differential Phase:    0.03°
K-Factor:    <0.05%
Signal to Noise Ratio:    72dB @ 5MHz
Controls:    Internal ID BIT switch; internal analog/TTL switches for setting the sync
Coupling:     DC
Options:     RK-3T 19" rack adapter
Power Requirements:    5VDC. 130mA
Dimensions (WxDxH):    4.8 x 2.8 x 1" (122 x 71 x 25mm)
Weight:    0.7 lbs (0.3kg)
