TVLogic LVM-241S 24'' FHD High-end LCD Monitor

by TVLogic
Raspoloživost: Isporuka 14-20 dana
  • 1920 x 1200 Resolution
  • 400cd/m² Brightness
  • 1500:1 Contrast Ratio
  • 178° Viewing Angles
5.166,25 €/38.925,11kn 4.133,00 €/31.140,09kn
Tečaj konverzije: 1 EUR = 7,53450 HRK

Sadržaj pakiranja

  • TVLogic 24" High-End WUXGA LCD Monitor
  • AC Power Cord
  • Desktop Stand
  • Limited 2-Year Warranty on Hardware

The 24" High-End WUXGA LCD Monitor from TVLogic supports video at resolutions up to 1920 x 1200. It features a brightness of 400cd/m2, a contrast ratio of 1500:1, and supports 178° viewing angles. This monitor has Analog, 3G-SDI, HDMI, DVI, SDI, and audio ports for connectivity. It supports Ethernet control. A power cable and desktop stand are included with the monitor.

  • The audio level meter displays the level of the embedded sound signal together with the video signal input through the terminal, such as SDI or HDMI
  • Closed caption
  • Blue only/mono function to adjust the color tones (tones and saturation) of the screen using the SMPTE color bar
  • Focus assist assigns a color to the pixels on the boundaries of the image to inform the user to achieve the best focus
  • H/V delay allows you to check the blanking area and synchronize signals by displaying the horizontal and vertical intervals in the center of the screen
  • Key lock locks the knob or key control
  • Marker displays various kinds of aspect ratios on the screen
  • Range Error analyzes the input signal's luma and chroma information; if the input signal exceeds the designated minimum value and maximum value, the pixel blinks
  • Timecode information is displayed on the screen
  • User aspect adjusts the width/height display ratio
  • Overscan function for extra area around the four edges of the image that may not be seen reliably by the viewer
  • Underscan function constrains the size of the image so the monitor shows everything the camera is seeing
  • 1:1 pixel function displays the original image resolution without scaling to match a certain resolution or an aspect ratio
  • Waveform Y displays the luma YCbCr component of the input signal into waveform
  • Vectorscope displays the color components 'B-Y' and 'R-Y' of the input signals onto the X-Y axis
  • Camera LUT applies the LUTs to the outbound log signal
  • 1:1 pixel mapping modes for SD/HD display the original image resolution without scaling to match a certain resolution or an aspect ratio
  • Supports 3G-SDI Level A/B input
  • UMD displays user-customized eight characters, source ID, or tally signal of ancillary (ANC) data on the screen
  • PbP (Picture-by-Picture) supports displaying multiple inputs on the screen at the same time
  • The HDR emulation function allows users to check how an HDR image will look on location
  • Custom 3D LUT import allows you to load your 3D-LUT files to an NLE software like Davinci Resolve via USB flash memory and display your LUT on VFM-055A or F-7H
  • Fast mode
TVLogic LVM-241S Specs
Panel Type IPS-Type LCD
Display Size 24.00" / 61.0 cm
Aspect Ratio 16:10
Viewing Angle Horizontal: 178°
Vertical: 178°
Touchscreen No
Maximum Brightness 400 cd/m2
Contrast Ratio 1500:01:00
Bit Depth / Color Support 10-Bit (1.07 Billion Colors)
Pixels Per Inch (ppi) 92 ppi
Real-Time LUT Monitoring HDR
Image Controls Blue Only, Focus Assist, H/V Delay, Overrange Detection, Screen Markers, Underscan, Vectorscope, Waveform
Video 3 x BNC Input
2 x BNC (3G-SDI) Input
1 x HDMI Type A Input
1 x DVI-I Input
3 x BNC Output
2 x BNC (SD-SDI) Output
Audio 1 x 1/8" / 3.5 mm Input
1 x 1/8" / 3.5 mm Output
Built-In Speaker None
Other I/O 1 x GPI (RJ45)
1 x LAN (RJ45)
2 x RS-422 (RJ45)
1 x USB 2.0 (USB Type-A)
1 x LAN (RJ45)
Card Slot None
Format Support
Gamma Curve HDR-HLG, HDR-PQ, Sony S-Log 3
Battery Type None
Mounting None
Dimensions 21.8 x 15.3 x 3.9" / 552.5 x 389 x 98.5 mm
23.1 x 16.4 x 5.9" / 586 x 416.8 x 150 mm, Including Stand
Weight 19.40 lb / 8.8 kg
